产品名称：冲击钻
产品详情
冲击钻
ID07
ID07为大扭矩冲击扳手，用于紧固或拆除螺帽和驱动螺栓。冲击扭矩可达500 ft. lbs. / 675 Nm.。可配摩擦圈或销式套筒护圈。
产品特点：
● 大号扳机
● 倒流检查阀可预防冲击钻回击
● 内置开中位或闭中位选择
● 羽式开关
● 7/16快换接头或1/2 in 驱动方头
The ID07 is a high torque impact wrench used for tightening and loosening nuts and driving lag bolts. Delivers impact torque of up to 500 ft. lbs. / 675 Nm. Available with friction ring or pin type socket retainer.
● Reverse-flow check valve prevents operation if the tool is plumbed backwards
● Built in selector for Open Center or Closed Center systems
● Feathering ON/OFF
● 7/16 quick change chuck or 1/2 inch square drive
件号 | FLOW RANGE 流量范围 | WEIGHT 重量 | LENGH 长度 | WIDTH 宽度 | CAPACITY 驱动头规格 | TORQUE 扭矩 | MISC 备注 |
ID07810 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 7/16 in QC | 500 ft lbs | |
ID0781001 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 7/16 in QC | 500 ft lbs | CE |
ID07815 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 7/16 in QC | 500 ft lbs | 扳机护罩 |
ID07820 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 1/2 in Sq Drive | 500 ft lbs | 挡圈固定 |
ID07830 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 1/2 in Sq Drive | 500 ft lbs | 摩擦环固定 |
ID0782001 | 4-12 gpm / 15-45 lpm | 7 lbs / 3.3 kg | 9 in. / 23 cm | 5 in. / 11 cm | 1/2 in Sq Drive | 500 ft lbs | CE |
